The hammer mill is widely used for crushing biomass materials into powder. All kinds of biomass materials are applicable, such as wood branches, wood chips, leaves, all kinds of wooden wastes, rice husk, cotton stalks, coconut shell, lump charcoal, etc. After crushing, the final powder will be with size less than 5mm, which can be used for making pellets, briquettes and other products.
Our hammer mill has high quality and better performance. Here are some main advantages as following.
1. The hammer mill is equipped with a cyclone and dust collector, which makes it more environmental friendly.
2. The hammers are made from alloy steel, and heat treated.
3. The whole machine is assembled on a special assembly platform, all components can be assembled together more accurately.
The specifications as following.
|
Model |
Power |
Capacity(kg/h) |
Weight(kg) |
Packing size(m) |
|
HSCP-E158 |
2.2kw |
80-150 |
75/85 |
0.75*045*0.73 |
|
HSCP-E195 |
4 kw |
100-300 |
120/140 |
0.9*0.58*1.02 |
|
HSCP-E420 |
7.5kw |
300-600 |
225/255 |
1.12*0.82*1.07 |
|
HSCP-E420 |
11 kw |
400-700 |
260/290 |
1.12*0.82*1.07 |
|
HSCP-D420 |
15Hp |
300-600 |
330/360 |
1.43*0.73*1.09 |
|
HSCP-D420 |
22Hp |
400-700 |
360/390 |
1.43*0.73*1.09 |
|
HSCP-E500 |
22kw |
800-1000 |
600/630 |
1.24*0.97*1.06 |
|
HSCP-D500 |
55Hp |
700-900 |
800/840 |
1.5*1.42*1.23 |
|
HSCP-E550 |
30kw |
800-1000 |
630/660 |
1.3*0.97*1.15 |
|
HSCP-E600 |
45kw |
800-1000 |
600/700 |
1.66*1.2*1.77 |
|
HSCP-E630 |
30+7.5kw |
1500-2000 |
1500/1700 |
2*1.1*1.7 |
